Omron Proximity Sensor TL-L Series

Quick Details
Place of Origin:Germany
Brand Name:Omron
Model Number:TL-L
Usage:Humidity Sensor
Theory:Current Sensor
Output:Analog Sensor
Model:TL-L
Name:Omron Proximity SensorTL-L
Accuracy:0.5%FS

proximity sensor

Omron Proximity Sensor TL-L Series

Features:

Equipped with water type

species:
Shape Detection Distance Output Type Model

Cylindrical type

(Flat mounting) 100mm Current output type TL-L100-7 1M

Note: water type (JIS0920 water type: pressure 0.39MPa)

equipped with TL-L100-10.

Rating:

Output specification Current output type

TL-L100-7

Detection distance 100mm ± 10%

Set the distance 0 ~ 80mm

Should be less than 15% of the detection distance

Can detect objects magnetic metal, non-magnetic metal

Standard detection of objects iron 200 × 200 × 1mm

Response time is less than 100ms

voltage

(Using voltage range) DC10 ~ 30V Ripple (p-p) 10%

Current consumption below DC40mA

Control output (residual voltage) DC200mA or less (1V or less)

Indicator action display (red)

Action mode

(Near the detection object) NO For details, see the timing

diagram in the “Input Output Section Circuit Diagram”

Protection circuit reverse protection, surge absorption

Ambient temperature range of work, save: the -25 ~ +55 ℃ (no icing, condensation)

Ambient temperature range of work, when stored: 35 ~ 95% RH (no condensation)

The temperature of -10 ~ +40 ℃ temperature range +20 ℃,

the detection distance of 30% or less

Voltage in the rated power supply voltage within ± 10% of

the range, the rated power supply voltage, the detection of the distance

± 5% or less

Insulation resistance 5MΩ or more (DC500V megger) The

charging unit is integral with the housing

Withstand voltage AC500V 50 / 60Hz 1min charging part

between the whole and the shell

Vibration (durable) 10 ~ 55Hz up and down amplitude 1.5mm X, Y, Z direction 2h

Impact (durable) 200m / s2 X, Y, Z direction 10 times

Protection structure IEC standard

Connection type Wire lead type (standard wire length 1m)

After mass (after packaging) about 1.5kg

Material shell: aluminum die-casting detection surface:

epoxy resin

Accessories manual
