Yokogawa EJA115E Low Flow Pressure Transmitter

Yokogawa EJA115E -DH Low Flow Pressure Transmitter

The low flow transmitter EJA115E is a differential
pressure transmitter assembled with an integral
orifice and excellent for very low flow measurement.
It outputs a 4 to 20 mA DC signal corresponding to
the measured flow.

• Power Supply Effects(Output signal code D and J)
  ±0.005 % per Volt (from 21.6 to 32 V DC, 350Ω)
• Stability (All normal operating condition, including
  overpressure effects)
  M and H capsules
  ±0.1% of URL per 7 years
• Weight
  [Installation code 7, 8 and 9]
  4.5 kg (9.9 lb) for measurement span code M and H
  without integral indicator and mounting bracket.
  5.4 kg (11.9 lb) for measurement span code F without
  integral indicator and mounting bracket.
  Add 1.5 kg (3.3 lb) for Amplifier housing code 2.

Yokogawa EJA115E  Low Flow Pressure Transmitter

Yokogawa EJA115E -DH Low Flow Pressure Transmitter

□ NORMAL OPERATING CONDITION
(Optional features or approval codes may
affect limits.)
Ambient Temperature Limits
−40 to 85°C (−40 to 185°F)
−30 to 80°C (−22 to 176°F) with LCD display
Process Temperature Limits
−40 to 120°C (−40 to 248°F)
Ambient Humidity Limits
0 to 100% RH
Working Pressure Limits (Silicone oil)
Maximum Pressure Limits
All capsules 16 MPa (2300 psi)
Minimum Pressure Limit
See graph below

Supply Voltage “◊”
For 4 to 20 mA HART / BRAIN
(Output signal code D and J)
10.5 to 42 V DC for general use and flameproof type.
10.5 to 32 V DC for lightning protector
(option code /A.)
10.5 to 30 V DC for intrinsically safe, type n, or nonincendive.
Minimum voltage limited at 16.6 V DC for digital
communications, BRAIN and HART
For 1 to 5 V HART (Output signal code Q)
Power supply :
9 to 28 V DC for general use and flame proof type.
Power Consumption :
0.96 mA to 3 mA, 27 mW

Yokogawa EJA115E Low Flow Pressure Transmitter

Yokogawa EJA115E Low Flow Pressure Transmitter

Yokogawa EJA115E -DM Low Flow Pressure Transmitter

The low flow transmitter EJA115E is a differential
pressure transmitter assembled with an integral
orifice and excellent for very low flow measurement.
It outputs a 4 to 20 mA DC signal corresponding to
the measured flow.

• Power Supply Effects(Output signal code D and J)
  ±0.005 % per Volt (from 21.6 to 32 V DC, 350Ω)
• Stability (All normal operating condition, including
  overpressure effects)
  M and H capsules
  ±0.1% of URL per 7 years
• Weight
  [Installation code 7, 8 and 9]
  4.5 kg (9.9 lb) for measurement span code M and H
  without integral indicator and mounting bracket.
  5.4 kg (11.9 lb) for measurement span code F without
  integral indicator and mounting bracket.
  Add 1.5 kg (3.3 lb) for Amplifier housing code 2.

Yokogawa EJA115E  Low Flow Pressure Transmitter

Yokogawa EJA115E -DM Low Flow Pressure Transmitter

□ NORMAL OPERATING CONDITION
(Optional features or approval codes may
affect limits.)
Ambient Temperature Limits
−40 to 85°C (−40 to 185°F)
−30 to 80°C (−22 to 176°F) with LCD display
Process Temperature Limits
−40 to 120°C (−40 to 248°F)
Ambient Humidity Limits
0 to 100% RH
Working Pressure Limits (Silicone oil)
Maximum Pressure Limits
All capsules 16 MPa (2300 psi)
Minimum Pressure Limit
See graph below

Supply Voltage “◊”
For 4 to 20 mA HART / BRAIN
(Output signal code D and J)
10.5 to 42 V DC for general use and flameproof type.
10.5 to 32 V DC for lightning protector
(option code /A.)
10.5 to 30 V DC for intrinsically safe, type n, or nonincendive.
Minimum voltage limited at 16.6 V DC for digital
communications, BRAIN and HART
For 1 to 5 V HART (Output signal code Q)
Power supply :
9 to 28 V DC for general use and flame proof type.
Power Consumption :
0.96 mA to 3 mA, 27 mW

Yokogawa EJA115E Low Flow Pressure Transmitter

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitter

Yokogawa EJA438E -JB Diaphragm Sealed Gauge Pressure Transmitter

The EJA438E Diaphragm Sealed Gauge Pressure
Transmitters can be used to measure liquid, gas,
or steam pressure.

• Power Supply Effects(Output signal code D and J)
  ±0.005 % per Volt (from 21.6 to 32 V DC, 350Ω)
• Response Time (All capsules) “◊”
  200 ms (approximate value at normal temperature)
  When software damping is set to zero and including
  dead time of 45 ms (nominal)
• Weight
  Flush type: 9.8 kg (21.6 lbs)
  (3-inch ANSI Class150 flange, capillary length 5 m;
  without integral indicator and mounting bracket.)
  Extended type: 12.2 kg (26.9 lbs)
  (4-inch ANSI Class150 flange, extention length
  (X2)=100 mm, capillary length 5 m; without integral
  indicator and mounting bracket.)
  Add 1.5kg (3.3lb) for Amplifier housing code 2.

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitter

Yokogawa EJA438E -JB Diaphragm Sealed Gauge Pressure Transmitter

□ NORMAL OPERATING CONDITION
(Optional features or approval codes may
affect limits.)
Ambient Temperature Limits
−40 to 60°C (−40 to 140°F)
−30 to 60°C (−22 to 140°F) with LCD display
(Note: The ambient temperature limits must be within the
fill fluid operating temperature range, see table 1.)
Process Temperature Limits
See table 1.
Ambient Humidity Limits
0 to 100% RH
Working Pressure Limits
See table 1.
For atmospheric pressure or below, see figure 1-1,
1-2, 1-3, 1-4, and 1-5.

Supply Voltage “◊”
For 4 to 20 mA HART / BRAIN
(Output signal code D and J)
10.5 to 42 V DC for general use and flameproof type.
10.5 to 32 V DC for lightning protector
(option code /A.)
10.5 to 30 V DC for intrinsically safe, type n, or nonincendive.
Minimum voltage limited at 16.6 V DC for digital
communications, BRAIN and HART
For 1 to 5 V HART (Output signal code Q)
Power supply :
9 to 28 V DC for general use and flame proof type.
Power Consumption :
0.96 mA to 3 mA, 27 mW

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitter

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitter

Yokogawa EJA438E -JA Diaphragm Sealed Gauge Pressure Transmitter

The EJA438E Diaphragm Sealed Gauge Pressure
Transmitters can be used to measure liquid, gas,
or steam pressure.

• Power Supply Effects(Output signal code D and J)
  ±0.005 % per Volt (from 21.6 to 32 V DC, 350Ω)
• Response Time (All capsules) “◊”
  200 ms (approximate value at normal temperature)
  When software damping is set to zero and including
  dead time of 45 ms (nominal)
• Weight
  Flush type: 9.8 kg (21.6 lbs)
  (3-inch ANSI Class150 flange, capillary length 5 m;
  without integral indicator and mounting bracket.)
  Extended type: 12.2 kg (26.9 lbs)
  (4-inch ANSI Class150 flange, extention length
  (X2)=100 mm, capillary length 5 m; without integral
  indicator and mounting bracket.)
  Add 1.5kg (3.3lb) for Amplifier housing code 2.

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitter

Yokogawa EJA438E -JA Diaphragm Sealed Gauge Pressure Transmitter

□ NORMAL OPERATING CONDITION
(Optional features or approval codes may
affect limits.)
Ambient Temperature Limits
−40 to 60°C (−40 to 140°F)
−30 to 60°C (−22 to 140°F) with LCD display
(Note: The ambient temperature limits must be within the
fill fluid operating temperature range, see table 1.)
Process Temperature Limits
See table 1.
Ambient Humidity Limits
0 to 100% RH
Working Pressure Limits
See table 1.
For atmospheric pressure or below, see figure 1-1,
1-2, 1-3, 1-4, and 1-5.

Supply Voltage “◊”
For 4 to 20 mA HART / BRAIN
(Output signal code D and J)
10.5 to 42 V DC for general use and flameproof type.
10.5 to 32 V DC for lightning protector
(option code /A.)
10.5 to 30 V DC for intrinsically safe, type n, or nonincendive.
Minimum voltage limited at 16.6 V DC for digital
communications, BRAIN and HART
For 1 to 5 V HART (Output signal code Q)
Power supply :
9 to 28 V DC for general use and flame proof type.
Power Consumption :
0.96 mA to 3 mA, 27 mW

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitter

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitter

Yokogawa EJA438E -JH Diaphragm Sealed Gauge Pressure Transmitter

The EJA438E Diaphragm Sealed Gauge Pressure
Transmitters can be used to measure liquid, gas,
or steam pressure.

• Power Supply Effects(Output signal code D and J)
  ±0.005 % per Volt (from 21.6 to 32 V DC, 350Ω)
• Response Time (All capsules) “◊”
  200 ms (approximate value at normal temperature)
  When software damping is set to zero and including
  dead time of 45 ms (nominal)
• Weight
  Flush type: 9.8 kg (21.6 lbs)
  (3-inch ANSI Class150 flange, capillary length 5 m;
  without integral indicator and mounting bracket.)
  Extended type: 12.2 kg (26.9 lbs)
  (4-inch ANSI Class150 flange, extention length
  (X2)=100 mm, capillary length 5 m; without integral
  indicator and mounting bracket.)
  Add 1.5kg (3.3lb) for Amplifier housing code 2.

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitter

Yokogawa EJA438E -JH Diaphragm Sealed Gauge Pressure Transmitter

□ NORMAL OPERATING CONDITION
(Optional features or approval codes may
affect limits.)
Ambient Temperature Limits
−40 to 60°C (−40 to 140°F)
−30 to 60°C (−22 to 140°F) with LCD display
(Note: The ambient temperature limits must be within the
fill fluid operating temperature range, see table 1.)
Process Temperature Limits
See table 1.
Ambient Humidity Limits
0 to 100% RH
Working Pressure Limits
See table 1.
For atmospheric pressure or below, see figure 1-1,
1-2, 1-3, 1-4, and 1-5.

Supply Voltage “◊”
For 4 to 20 mA HART / BRAIN
(Output signal code D and J)
10.5 to 42 V DC for general use and flameproof type.
10.5 to 32 V DC for lightning protector
(option code /A.)
10.5 to 30 V DC for intrinsically safe, type n, or nonincendive.
Minimum voltage limited at 16.6 V DC for digital
communications, BRAIN and HART
For 1 to 5 V HART (Output signal code Q)
Power supply :
9 to 28 V DC for general use and flame proof type.
Power Consumption :
0.96 mA to 3 mA, 27 mW

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitter

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitter

Yokogawa EJA438E -DB Diaphragm Sealed Gauge Pressure Transmitter

The EJA438E Diaphragm Sealed Gauge Pressure
Transmitters can be used to measure liquid, gas,
or steam pressure.

• Power Supply Effects(Output signal code D and J)
  ±0.005 % per Volt (from 21.6 to 32 V DC, 350Ω)
• Response Time (All capsules) “◊”
  200 ms (approximate value at normal temperature)
  When software damping is set to zero and including
  dead time of 45 ms (nominal)
• Weight
  Flush type: 9.8 kg (21.6 lbs)
  (3-inch ANSI Class150 flange, capillary length 5 m;
  without integral indicator and mounting bracket.)
  Extended type: 12.2 kg (26.9 lbs)
  (4-inch ANSI Class150 flange, extention length
  (X2)=100 mm, capillary length 5 m; without integral
  indicator and mounting bracket.)
  Add 1.5kg (3.3lb) for Amplifier housing code 2.

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitter

Yokogawa EJA438E -DB Diaphragm Sealed Gauge Pressure Transmitter

□ NORMAL OPERATING CONDITION
(Optional features or approval codes may
affect limits.)
Ambient Temperature Limits
−40 to 60°C (−40 to 140°F)
−30 to 60°C (−22 to 140°F) with LCD display
(Note: The ambient temperature limits must be within the
fill fluid operating temperature range, see table 1.)
Process Temperature Limits
See table 1.
Ambient Humidity Limits
0 to 100% RH
Working Pressure Limits
See table 1.
For atmospheric pressure or below, see figure 1-1,
1-2, 1-3, 1-4, and 1-5.

Supply Voltage “◊”
For 4 to 20 mA HART / BRAIN
(Output signal code D and J)
10.5 to 42 V DC for general use and flameproof type.
10.5 to 32 V DC for lightning protector
(option code /A.)
10.5 to 30 V DC for intrinsically safe, type n, or nonincendive.
Minimum voltage limited at 16.6 V DC for digital
communications, BRAIN and HART
For 1 to 5 V HART (Output signal code Q)
Power supply :
9 to 28 V DC for general use and flame proof type.
Power Consumption :
0.96 mA to 3 mA, 27 mW

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitter

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitter

Yokogawa EJA438E -DA Diaphragm Sealed Gauge Pressure Transmitter

The EJA438E Diaphragm Sealed Gauge Pressure
Transmitters can be used to measure liquid, gas,
or steam pressure.

• Power Supply Effects(Output signal code D and J)
  ±0.005 % per Volt (from 21.6 to 32 V DC, 350Ω)
• Response Time (All capsules) “◊”
  200 ms (approximate value at normal temperature)
  When software damping is set to zero and including
  dead time of 45 ms (nominal)
• Weight
  Flush type: 9.8 kg (21.6 lbs)
  (3-inch ANSI Class150 flange, capillary length 5 m;
  without integral indicator and mounting bracket.)
  Extended type: 12.2 kg (26.9 lbs)
  (4-inch ANSI Class150 flange, extention length
  (X2)=100 mm, capillary length 5 m; without integral
  indicator and mounting bracket.)
  Add 1.5kg (3.3lb) for Amplifier housing code 2.

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitter

Yokogawa EJA438E -DA Diaphragm Sealed Gauge Pressure Transmitter

□ NORMAL OPERATING CONDITION
(Optional features or approval codes may
affect limits.)
Ambient Temperature Limits
−40 to 60°C (−40 to 140°F)
−30 to 60°C (−22 to 140°F) with LCD display
(Note: The ambient temperature limits must be within the
fill fluid operating temperature range, see table 1.)
Process Temperature Limits
See table 1.
Ambient Humidity Limits
0 to 100% RH
Working Pressure Limits
See table 1.
For atmospheric pressure or below, see figure 1-1,
1-2, 1-3, 1-4, and 1-5.

Supply Voltage “◊”
For 4 to 20 mA HART / BRAIN
(Output signal code D and J)
10.5 to 42 V DC for general use and flameproof type.
10.5 to 32 V DC for lightning protector
(option code /A.)
10.5 to 30 V DC for intrinsically safe, type n, or nonincendive.
Minimum voltage limited at 16.6 V DC for digital
communications, BRAIN and HART
For 1 to 5 V HART (Output signal code Q)
Power supply :
9 to 28 V DC for general use and flame proof type.
Power Consumption :
0.96 mA to 3 mA, 27 mW

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitter

Yokogawa EJA118E Diaphragm Sealed Differential Pressure Transmitter

Yokogawa EJA118E -JH Diaphragm Sealed Differential Pressure Transmitter

The EJA118E Diaphragm Sealed Differential Pressure
Transmitters can be used to measure liquid, gas,
or steam flow, as well as liquid level, density, and
pressure.

• Power Supply Effects(Output signal code D and J)
  ±0.005 % per Volt (from 21.6 to 32 V DC, 350Ω)
• Update Period “◊”
  Differential pressure: 45 ms
  Static pressure: 360 ms
• Accuracy
  Absolute Pressure
  1 MPa or higher: ±0.5% of span
  Less than 1 MPa: ±0.5%×(1 MPa/span) of span
  Gauge Pressure Reference
  Gauge pressure reference is 1013 hPa (1 atm)
  Note: Gauge pressure variable is based on the above
  fixed reference and thus subject to be affected by
  the change of atomospheric pressure.

Yokogawa EJA118E Diaphragm Sealed Differential Pressure Transmitter

Yokogawa EJA118E -JH Diaphragm Sealed Differential Pressure Transmitter

□ NORMAL OPERATING CONDITION
(Optional features or approval codes may
affect limits.)
Ambient Temperature Limits
−40 to 60°C (−40 to 140°F)
−30 to 60°C (−22 to 140°F) with LCD display
(Note: The ambient temperature limits must be within the
fill fluid operating temperature range, see table 1.)
Process Temperature Limits
See table 1.
Ambient Humidity Limits
0 to 100% RH
Working Pressure Limits
See table 1.
For atmospheric pressure or below, see figure 1-1,
1-2, 1-3, 1-4, and 1-5

Supply Voltage “◊”
For 4 to 20 mA HART / BRAIN
(Output signal code D and J)
10.5 to 42 V DC for general use and flameproof type.
10.5 to 32 V DC for lightning protector
(option code /A.)
10.5 to 30 V DC for intrinsically safe, type n, or nonincendive.
Minimum voltage limited at 16.6 V DC for digital
communications, BRAIN and HART
For 1 to 5 V HART (Output signal code Q)
Power supply :
9 to 28 V DC for general use and flame proof type.
Power Consumption :
0.96 mA to 3 mA, 27 mW

Yokogawa EJA118E Diaphragm Sealed Differential Pressure Transmitter

Yokogawa EJA118E Diaphragm Sealed Differential Pressure Transmitter

Yokogawa EJA118E -JM Diaphragm Sealed Differential Pressure Transmitter

The EJA118E Diaphragm Sealed Differential Pressure
Transmitters can be used to measure liquid, gas,
or steam flow, as well as liquid level, density, and
pressure.

• Power Supply Effects(Output signal code D and J)
  ±0.005 % per Volt (from 21.6 to 32 V DC, 350Ω)
• Update Period “◊”
  Differential pressure: 45 ms
  Static pressure: 360 ms
• Accuracy
  Absolute Pressure
  1 MPa or higher: ±0.5% of span
  Less than 1 MPa: ±0.5%×(1 MPa/span) of span
  Gauge Pressure Reference
  Gauge pressure reference is 1013 hPa (1 atm)
  Note: Gauge pressure variable is based on the above
  fixed reference and thus subject to be affected by
  the change of atomospheric pressure.

Yokogawa EJA118E Diaphragm Sealed Differential Pressure Transmitter

Yokogawa EJA118E -JM Diaphragm Sealed Differential Pressure Transmitter

□ NORMAL OPERATING CONDITION
(Optional features or approval codes may
affect limits.)
Ambient Temperature Limits
−40 to 60°C (−40 to 140°F)
−30 to 60°C (−22 to 140°F) with LCD display
(Note: The ambient temperature limits must be within the
fill fluid operating temperature range, see table 1.)
Process Temperature Limits
See table 1.
Ambient Humidity Limits
0 to 100% RH
Working Pressure Limits
See table 1.
For atmospheric pressure or below, see figure 1-1,
1-2, 1-3, 1-4, and 1-5

Supply Voltage “◊”
For 4 to 20 mA HART / BRAIN
(Output signal code D and J)
10.5 to 42 V DC for general use and flameproof type.
10.5 to 32 V DC for lightning protector
(option code /A.)
10.5 to 30 V DC for intrinsically safe, type n, or nonincendive.
Minimum voltage limited at 16.6 V DC for digital
communications, BRAIN and HART
For 1 to 5 V HART (Output signal code Q)
Power supply :
9 to 28 V DC for general use and flame proof type.
Power Consumption :
0.96 mA to 3 mA, 27 mW

Yokogawa EJA118E Diaphragm Sealed Differential Pressure Transmitter

Yokogawa EJA118E Diaphragm Sealed Differential Pressure Transmitter

Yokogawa EJA118E -DH Diaphragm Sealed Differential Pressure Transmitter

The EJA118E Diaphragm Sealed Differential Pressure
Transmitters can be used to measure liquid, gas,
or steam flow, as well as liquid level, density, and
pressure.

• Power Supply Effects(Output signal code D and J)
  ±0.005 % per Volt (from 21.6 to 32 V DC, 350Ω)
• Update Period “◊”
  Differential pressure: 45 ms
  Static pressure: 360 ms
• Accuracy
  Absolute Pressure
  1 MPa or higher: ±0.5% of span
  Less than 1 MPa: ±0.5%×(1 MPa/span) of span
  Gauge Pressure Reference
  Gauge pressure reference is 1013 hPa (1 atm)
  Note: Gauge pressure variable is based on the above
  fixed reference and thus subject to be affected by
  the change of atomospheric pressure.

Yokogawa EJA118E Diaphragm Sealed Differential Pressure Transmitter

Yokogawa EJA118E -DH Diaphragm Sealed Differential Pressure Transmitter

□ NORMAL OPERATING CONDITION
(Optional features or approval codes may
affect limits.)
Ambient Temperature Limits
−40 to 60°C (−40 to 140°F)
−30 to 60°C (−22 to 140°F) with LCD display
(Note: The ambient temperature limits must be within the
fill fluid operating temperature range, see table 1.)
Process Temperature Limits
See table 1.
Ambient Humidity Limits
0 to 100% RH
Working Pressure Limits
See table 1.
For atmospheric pressure or below, see figure 1-1,
1-2, 1-3, 1-4, and 1-5

Supply Voltage “◊”
For 4 to 20 mA HART / BRAIN
(Output signal code D and J)
10.5 to 42 V DC for general use and flameproof type.
10.5 to 32 V DC for lightning protector
(option code /A.)
10.5 to 30 V DC for intrinsically safe, type n, or nonincendive.
Minimum voltage limited at 16.6 V DC for digital
communications, BRAIN and HART
For 1 to 5 V HART (Output signal code Q)
Power supply :
9 to 28 V DC for general use and flame proof type.
Power Consumption :
0.96 mA to 3 mA, 27 mW

Yokogawa EJA118E Diaphragm Sealed Differential Pressure Transmitter
